The MM-F series induction gold melting furnace is an advanced equipment designed for melting gold, silver, copper, and other non-ferrous metals. It utilizes high-power dual semiconductor module technology, ensuring strong output power and high stability. With multiple protection functions such as over-voltage, over-current, low water level, and overheat protection, this furnace offers low failure rates and high reliability. Operators can digitally set the melting temperature, and the furnace includes insulation capabilities for efficient heat retention. It operates at 100% full load with the ability to work continuously for 24 hours, boasting rapid heating and energy-saving features that minimize melting costs. Its cabinet design makes it compact, lightweight, and easy to install and operate.
Model | Z.M.MF.ML001 | Z.M.MF.ML001-T |
| Name | 1KG Mini furnace without temp control | 1KG Mini furnace with temp control |
Voltage | AC220V 50/60HZ | AC220V 50/60HZ |
Power input | 3KW | 3KW |
| Phase | 1 | 1 |
Max temp of machine | 1300°C | 1300°C |
Melting capacity | 1KG | 1KG |
Melting speed | 3 ~ 4.5min | 3 ~ 4.5min |
Color | orange / blue | orange / blue |
Size | 58x33x30cm | 58x33x30cm |
| Net weight | 28KG | 28KG |
Warranty | 1 year | 1 year |
Product Features:
Advanced MM-F series induction technology
High-power dual semiconductor module
Multiple safety protections: over-voltage, over-current, low water level, overheat
Digital temperature setting with insulation function
100% full load capacity, 24-hour continuous operation
