RMKBE Wax injector
3)Wax chamber temp range ：55-85℃(±1℃)
4)Nozzle temp range ：55-85℃(±1℃)
5)Wax chamber capacity ：3Kg
6)Store Programs：100 groups of one key control ,and one group of non-one key control
7)Standard clamp size： L135 × W105 × D45(max)
8)Bigger clamp size：L135 × W135 × D60（Max）
9)Touch screen,Induction function
1.To make the high leavel wax injector with application of Japanese advanced technology parts and workmanship standard
2.This machine is equipped with manual lifting clamps With no request on any tools the operator can easily and accrately adjust the postion of the rubber mould upwards or downward which makes it easier for the rubber to align the wax injection nozzle.
Power Supply： AC220±10%V,50/60HZ,1Phase
Power Input ：500W
External input pressure： 0.4~0.7MPa
Pressure regulator setting range ：0.25~0.3MPa
Pressure sensor display range： -5~240KPa
Mold Clamp pressure setting range ：30~235Kpa
Mold forward pressure setting range： 65~235Kpa
Wax tank setting pressure： Less 200Kpa
Fuse specification ：5A/250V
Mold hold mould setting range ：0~300(s)
Wax tank capacity ：3kg
Heating temperature range of wax bath： 0-95℃
Wax nozzle heating temperature range： 0-95℃
Vacuum time setting range： 0~20(s)
Injection time setting range： 0~20(s)
Maximum workpiece count ：0~9
Total amount of data stored ：1000 group
Start ：magnetic induction or button
Rubber model specification (Regular)： H45 x W 105X L 135(Normal)
Rubber model specification (Larger) ：H60 X W 135 x L 135(max)
Packaging & Shipping
We can offer Standard carton,Wooden box,Pallat packages,etc.
We can send it by air,by train,by car,by sea,according to your according to your requirements.
We can offer life time service of this machine,
1years warranty of machine,free parts and delivery,
we can offer free trianing to your in our factories,
send our engineers to your factories and office,
Video call and online service.
We have Showroom and distributor all over the world,can offer location service to yours.
Yihui Casting Technology Co., Ltd, established in March, 2003, through more than10 years effort, has developed as a professional supplier in providing integrated lost wax casting solutions, manufacturing jewelry casting machines and materials, specializing in casting technology research & development and application. Under Yihui brand, we own Shenzhen Yihui Casting
Technology Co., Ltd, Guangzhou Ruihui Casting Machinery Co., Ltd, Shenzhen Xinhui Casting Material Co., Ltd., Dongguan Yihui Casting Technology Co., Ltd, Guangzhou Yihui Jewelry Tools Co., Ltd, and other manufacturing and selling companies.
Additionally, Yihuicasting have graphite products making factory, ceramic products making factory, machines making factory. Relying on Yihui brand, centering on casting realted products, complete products supplying system has been formed, meanwhile, we are agent of world known brand jewlery tools and consumables. Products range covers all the jewelry making procedures, which are widely used in jewelry, watches, glasses, dental, glaze, and other precision loss wax casting industry, which have been exported far to South-east Asia, Mid-east, European and American countries.
We will offer a free bags wax beads to you,which quantity in 11.35KGS,if you purchase our IW-PRO wax injector in
1th April 2021 to 31th December,2021.
If you have Interesting in it,feel free to contact us.
